Electroless Nickel Plating

Industrial Electroless Nickel Plating (MIL-C-26074, AMS 2404, ASTM B-733 standards):

Advanced Surface Technologies specializes in high quality Electroless Nickel Plating. Electroless Nickel is a high quality engineering coating for corrosion resistance, hardness, lubricity, solderability and wear resistance. The advantage that Electroless Nickel has over almost all other plated coatings is the uniformity of the nickel deposit thickness. Without the high and low current density found in electrolytic plating processes, Electroless nickel can deposit into recesses without burning or having excessive thickness on the outer edges of a part. The coating conforms exactly to the surface finish of the part so cosmetic finishes will be enhanced by the Electroless Nickel deposit. Advanced Surface Technologies’ Electroless Nickel coatings conform to AMS2404, ASTM B733 and MIL-C-26074.

Being a leader in Electroless Nickel plating AST has 8 Electroless Nickel process lines that are substrate specific. Cleaning and alloy perpetration are extremely important to the quality of the Electroless Nickel deposit and using chemistries that are specifically designed to clean each alloy allows AST to provide the quality expected, even on the most difficult of parts.

There are many different types of Electroless Nickel coatings and processes available to meet a wide range of unique applications. Physical and mechanical properties vary considerably from one Electroless Nickel process to another depending on the phosphorus content, the formulation of the bath and both the pre-plate and post-plate treatments, yet all the Electroless Nickel coatings offer excellent deposit uniformity and superior corrosion protection.

Electroless Nickel plating is a chemical process that involves several simultaneous reactions in an aqueous solution, which occur without the use of external electrical power. The reaction is accomplished when hydrogen is released by a reducing agent (normally sodium hypophosphite), and oxidized thus producing a negative charge on the surface of the part. The charge causes a layer of nickel and phosphorus to form and this continues until the part is removed from the solution. Since the plating process requires no electrical current, the coating produced is a very uniform structure that can be applied over various metals and substrates.

Our experienced staff can construct custom solutions for your distinct finishing needs. If its corrosion protection, solderability, hardness, cosmetics or lubricity we can help you achieve the final product.

ELECTROLESS NICKEL PLATING

Electroless nickel is the preferred engineering coating solution for applications requiring high levels of corrosion and wear resistance, deposit uniformity and hardness, lubricity, and solderability. Electroless nickel plating is an autocatalytic chemical process used to deposit a uniform layer of nickel-phosphorous alloy onto stainless steel, copper, aluminum, or brass workpiece, without the necessity of applying electrical current.

Advanced Surface Technologies provides the highest quality electroless nickel plating services available for coating irregularly shaped parts, internal surfaces and cavities where assembly tolerances are critical, prototyping, and your other mission critical projects.

4 Decades of Custom Solutions for Your Unique Finishing Needs

By eliminating the electrical current necessary to perform traditional electrolytic plating processes, electroless nickel plating allows AST to place nickel deposits in hard-to-plate recesses without burning or excessive build up on the outer edges of parts. This unparallelled level of conformity to the plated surface, uniform thickness, and atomic-level smoothness enhances cosmetic finishes, allows repair or salvage of complex machine components, high tech applications such as computer hard drive coating, and other custom solutions for demanding applications in a wide range of industries.

A Leader in Electroless Nickel Plating Since 1980

  • 8 substrate- and size-specific electroless nickel plating process lines
  • Alloy-specific cleaning chemistries allow AST to provide the highest quality matte, semi-bright, or bright finishes on even the most complex and difficult to coat parts
  • Environmentally aware shop – utilizing extensive wastewater minimization programs for recycling waste
  • Meets virtually any requirement for Electroless Nickel finishing (including plating on magnesium)
  • On Time Every Time Delivery pledge
  • AST Electroless Nickel coatings conform to AMS 2404, ASTM B733 and MIL-C-26074 standards

Mil-C-26074, ASTM B733, AMS 2404

AST provides custom coating solutions per military spec Mil-C-26074, and AMS 2404 – the most widely recognized and long-standing specifications pertaining to Electroless Nickel plating. Our experienced staff can also fabricate solutions meeting ASTM B733, as well as other certifications, and are capable of meeting your company-specific specifications as well.

Advanced Surface Technologies is a national leader in the design, fabrication, and finishing of quality parts for the oil and gas, aerospace, solar, electronics, automotive, and other industries.

Call us today for high quality, price competitive, responsive turnaround surface plating services, and allow us to exceed your expectations.

Specifications

Classification Class 1: Except for hydrogen embrittlement relief, no post plating thermal treatment.
Class 2: Thermal treatment ar 450F (232C) or above to harden the deposit.
Class 3: Thermal treatment ar 375F (191C) to improve adhesion for nonheat treatable aluminum alloys and beryllium alloys.
Class 4: Thermal treatment at 250F (121C) to improve adhesion for heat treatable aluminum alloys.
Grade Grade A: .001” Minimum Thickness
Grade B: .0005” Minimum Thickness
Grade C: .0015 Minimum Thickness
Classification Class 1: Except for hydrogen embrittlement relief, no post plating thermal treatment.
Class 2: Thermal treatment ar 450F (232C) or above to harden the deposit.
Class 3: Thermal treatment ar 375F (191C) to improve adhesion for nonheat treatable aluminum alloys and beryllium alloys.
Class 4: Thermal treatment at 250F (121C) to improve adhesion for heat treatable aluminum alloys.
Grade Grade A: .001” Minimum Thickness
Grade B: .0005” Minimum Thickness
Grade C: .0015 Minimum Thickness
Type Type I: No Requirement for Phosphorus
Type II: 1-3% Phosphorus
Type III: 2-4% Phosphorus
Type IV: 5-9% Phosphorus
Type V: 10% and above Phosphorus
Service Condition SCO: Minimum thickness .000004” (0.1 um)
SC1: Light Service .0002” (5 um)
SC2: Mild Service .0005” (13um)
SC3: Moderate Service .001” (25 um)
SC4: Severe Service .003” (75 um)
Class Class 1: No Heat Treatment, As Plated
Class 2: Heat treatment for Maximum HardnessType I-
260C            20 hours
285C             16 hours
320C               8 hours
400C               1 hourType II- 350-380C       1 hourType III- 360-390C       1 hourType IV- 365-400C       1 hourType V- 375-400         1 hour
Class 3: Adhesion on Steel180-200C       2-4 hours
Class 4: Adhesion, Carburized Steel and Age Hardened Aluminum.120-130C       1-6 hours
Class 5: Adhesion on Beryllium and Aluminum.140-150C       1-2 hours
Class 6: Adhesion on Titanium300-320C       1-4 hours

Capabilities

Plating Capabilities Rack Plating LinesBarrel Plating Lines
Standards Met MIL-C-26074AMS 2404ASTM B-733

Additional Information

Industries Served AutomotiveAerospaceCommunicationsComputerElectronicsSolarHousehold AppliancesOil & Gas EquipmentMedical EquipmentRecreational EquipmentTool & DiePharmaceutical
Certifications ISO 9001:2000 Certified
Quality System Features Dedicated to company-wide continuous improvementIn-house laboratory facilities
Environmental System Features State-of-the-art, computer-controlled waste treatment system
Professional Associations and Awards
  • Charter member of the Strategic Goals Program, a cooperative effort between the metal finishing industry and EPA
  • National Association of Metal Finishers (NAMF)
  • American Electroplaters and Surface Finishers Society (AESF)
  • Recipient of the Colorado Environmental Leadership Award
Service Features
  • Production scheduling and production flexibility that minimize turnaround time
  • A staff that understands the importance of quick response for our customers
